The HOKI 800 Ballast Hopper Wagon is purpose-built for railway infrastructure maintenance and ballast distribution operations. Designed with a top-loading hopper and multiple discharge doors, the wagon enables controlled ballast unloading along the track, improving maintenance efficiency and reducing manual labor requirements.

With a payload capacity of 30 tons and a total operating weight of approximately 48 tons, the HOKI 800 is capable of supporting large-scale ballast renewal and track maintenance projects. The wagon is equipped with six discharge doors that allow ballast to be distributed through side and center outlets, providing flexibility for various maintenance applications.

Built for 1,067 mm gauge railways and fitted with air brakes, AAR10A couplers, and cast-type bogies, the HOKI 800 delivers dependable performance and durability in demanding railway operating environments.

Specifications
General
·        Vehicle Type: Ballast Hopper Wagon

·        Model: HOKI 800

·        Track Gauge: 1,067 mm

Weight
·        Tare Weight: 17.5 Tons

·        Payload Capacity: 30.0 Tons

·        Total Operating Weight: Approximately 48 Tons

·        Hopper Capacity: 18 m³

Dimensions
·        Length: 12,500 mm

·        Length Including Couplers: Approximately 13,300 mm

·        Width: Approximately 2,742 mm

·        Height Above Rail Level: 2,900 mm

Running Gear
·        Bogie Type: Cast Type

·        Coupler Type: AAR10A

·        Brake Type: Air Brake

Loading & Unloading
·        Loading Method: Top Loading

·        Discharge Method: Side and Center Discharge

·        Number of Discharge Doors: 6

·        Discharge Operation: Manual

Performance
·        Maximum Operating Speed: 80 km/h

Key Features
·        Purpose-built ballast transportation wagon

·        30-ton payload capacity

·        18 m³ ballast hopper capacity

·        Six discharge doors for controlled ballast distribution

·        Side and center unloading system

·        Air brake system for safe operation

·        Heavy-duty cast bogies

·        Ideal for railway maintenance and track renewal projects

Applications
·        Ballast Distribution

·        Railway Track Construction

·        Ballast Renewal Projects

·        Track Maintenance Operations

·        Railway Infrastructure Development

·        Maintenance-of-Way Operations
